Y64 is an industrial-grade, electrically isolated 1-channel CAN bus expansion module designed for the ARMxy series ARM-based embedded industrial computers. It provides 1 CAN bus interface using SPI-to-CAN 2.0B conversion, supporting CAN communication speeds up to 1000 kbps. It is suitable for industrial automation, machine control, and monitoring systems. Note: The Y64 module is not supported by the EdgeIO Series.
| No. | Model | Signal Type |
|---|---|---|
| 1 |
Y01 |
4xDI+4xDO(NPN) |
| 2 |
Y02 |
4xDI+4xDO(PNP) |
| 3 |
Y11 |
8xDI(NPN) |
| 4 |
Y12 |
8xDI(PNP) |
| 5 |
Y13 |
8xDI(Dry Contact) |
| 6 |
Y21 |
8xDO(PNP) |
| 7 |
Y22 |
8xDO(NPN) |
| 8 |
Y24 |
4xDO(Relay) |
| 9 |
Y31 |
4xAI, Single-ended, 0~20mA/4~20mA |
| 10 |
Y33 |
4xAI, Single-ended, 0~5V/0~10V |
| 11 |
Y34 |
4xAI, Differential, 0~5V/0~10V |
| 12 |
Y35 |
7x NTC Input |
| 13 |
Y36 |
4xAI, Differential, ±5V/±10V |
| 14 |
Y41 |
4xAO, 0~20mA/4~20mA |
| 15 |
Y42 |
1xAO, 0~5V/0~10V |
| 16 |
Y43 |
4xAO, 0~5V/0~10V |
| 17 |
Y46 |
4xAO, ±5V/±10V |
| 18 |
Y51 |
2xRTD, 3-Wire PT100 |
| 19 |
Y52 |
2xRTD, 3-Wire PT1000 |
| 20 |
Y53 |
2xRTD, 4-Wire PT100 |
| 21 |
Y54 |
2xRTD, 4-Wire PT1000 |
| 22 |
Y56 |
Resistance Measurement |
|
23 |
Y57 |
Voltage Measurement |
|
24 |
Y58 |
4xTC |
|
25 |
Y63 |
4xRS485 or RS232 |
|
26 |
Y64 |
1xCAN, CAN2.0B |
|
27 |
Y95 |
4xPWM Output(NPN) + 4xPulse Counter Input |
|
28 |
Y96 |
4xPWM Output(PNP) + 4xPulse Counter Input |
